DHS General Description
System Technology
The DHS product line incorporates state of the art digital technology for voice switching
and call processing utilizing Pulse Code Modulation and Time Division Multiplexing
(PCM/TDM). The DHS family is engineered to allow migration of the DHS digital terminals
and terminal accessories throughout the entire product line. ISDN-like, 2B+D technology
complements the system architecture and capabilities. On one industry standard twisted
pair, key telephones perform all system functions and voice communications. Some
additional features of the DHS include:
† A non-blocking switch, with no loss or degradation of voice signals.
† Stored-Program Control (SPC), utilizing a 16-bit, 8 MHz microprocessor.
† Memory consists of 512 KB of Read Only Memory (ROM) and 128 KB of Random
Access Memory (RAM).
When an analog device interface is required, a 2-Port Central Office (CO) Module may be
connected to any one digital station port. The 2B+D technology allows the DHS to split
one digital key telephone port voice channel (B1) and the second voice channel (B2) to
provide two independent SLT-type device interfaces.
The 2-Port CO Module may be expanded with the 2-Port Analog Expansion (in the 2-Port
CO Module housing).
The 2-Port CO Module and 2-Port Analog Expansion each require one dedicated digital
station port.
System Components
KSU Components
The DHS platform is comprised of three key telephone models, an optional Direct Station
Selector (DSS) and a modular Key Service Unit (KSU) which houses the following KSU
components:
† 3 x 8 Module
† Standard MOH/BGM Module
† 6-Port CO Module
† Option Module
The application of analog devices in the DHS has the effect of two-to-one
port gain. For every single digital port used to interface a 2-Port CO Module/
Expansion, two analog ports are available.
2-2 DHS General Description
Two 3 x 8 Modules may be added to the initial 3 x 8 module in the Basic KSU. Alternately,
a 6-Port CO Module may be substituted for one 3 x 8 module for greater flexibility. The
maximum capacity is either 9 CO lines x 24 stations, or 12 CO lines x 16 stations.
The basic KSU is equipped with a Standard Background Music/Music-On-Hold (BGM/
MOH) Module. An external music source may be connected to this interface via a 1/8 in.
phono plug for BGM/MOH listening. The Option Module replaces the Standard BGM/
MOH Module and provides two DTMF receivers and two Tone Detectors specifically for
ECF, DISA, Unsupervised CO Line Conference, and Dial Tone Detection.
External Components
† Executive Key Telephone
† Enhanced Key Telephone
† Basic Key Telephone
† 2-Port Analog Adapter
† 2-Port SLT Expansion
† Direct Station Selector
Table 2-1: System Configurations
Equipment Installed Maximum Number of
Loop Start Lines
Maximum Number of
DHS Digital Key
Telephones Vodavi Starplus Triad
One 3 x 8 module 3 8
Two 3 x 8 modules 6 16
Three 3 x 8 modules 9 24
One 3 x 8 module and
One six-port CO module
9 8
Two 3 x 8 modules and
One six-port CO module
12 16 Vodavi Starplus Triad
SLT operations do NOT use Option Module resources.
Key telephones are available in two colors: Off White, and Charcoal Gray.
DHS General Description 2-3
System Administration
The system default customer data base can be entered and changed, under password
control, from any Executive Key Telephone. All Customer information is protected by an
internal rechargeable NiCad or NiMh battery. Programmable password protection is
allowed for each station, system administrator and external (DISA) callers. An optional PC
Programming Software is available to program the DHS system. This Software allows the
user to program offline and then upload directly to the system. The DHS requires the
Option Module to use the PC Programming Software.
Key Service Unit (KSU)
The DHS Key Service Unit (KSU) is a modular flat-pack design. It is a self-contained cabinet
with internal power supply, common control circuits (CPU board) and 3 x 8 module. The Vodavi Starplus Triad
power supply AC transformer is hard-wire selected for either 117V AC (+10%). The KSU is
designed for wall mount and shipped with a wall mounting template. The compact KSU
weighs less than 20 pounds and is UL compliant.
Standard inserts installed over various KSU openings may be removed or repositioned
2-4 DHS General Description
Power Supply
The power supply circuitry of the DHS incorporates a linear design transformer with a
choice of input voltage taps. The transformer primary windings are shipped wired for
117V AC applications; a factory insulated tap wire may alternatively be connected for
230V AC applications. Since the power supply is linear in design the output voltage varies
between 21.6 and 32V DC depending on load and stability of the input voltage. The
output voltage is delivered to the CPU board for distribution and rectified there for logic
and control voltages.
Two fuses are equipped on the power supply board, one for AC input over-voltage
protection and one for DC output over-voltage protection. A Double Pole Double Throw Vodavi Starplus Triad
(DPDT) switch is accessible from outside of the KSU when the KSU cover is in place. The
DPDT switch will simultaneously switch AC input and DC output circuits ON and OFF.
In the event battery backup operation is desired and equipped via the optional DHS
Battery Charging Unit (BCU), the KSU switch may be used to switch OFF/ON power from
both sources.
The power supply wiring harness is equipped with a mate-n-lock connector on the DC
output for connection of the DHS BCU. When equipped, the BCU will maintain complete
system operation during commercial power outages. A current draw/configuration chart
is included in this document for assistance in selecting the appropriate batteries for use
in the BCU. Please consult the BCU manual for installation precautions and proper battery
installation.
Central Processor Unit (CPU)
The CPU board is standard in the KSU. This board contains all circuitry required to control
the fully-equipped DHS . Three bus connectors are provided where the station/CO line
interface 3 x 8 module and 6-Port CO Module are connected. The Option Module
connector and Standard MOH Module connector are also located on the CPU board. All
digital voice switching and call process data switching is accomplished on the CPU board.
3 x 8 Module Vodavi Starplus Triad
The 3 x 8 module provides interface of three loop-start CO lines and eight DHS key
telephones.
Each CO line circuit incorporates over-voltage protection, ring detector, loop detector,
loop/pulse-dial relay, current sink circuit, coupling/isolation transformer (impedance
600:Ohms), hybrid circuit and combo (CODEC and filter) polarity guard circuit and radio
frequency noise filter.
Each digital key telephone port is comprised of a proprietary transceiver designed using
ISDN type 2B+D architecture.
Physical connection of stations and CO lines to the 3 x 8 module is made through one
male 25-pair, amphenol-type connector to the Main Distribution Frame (MDF). Station
power and signaling to the digital key telephones are provided via a single twisted pair
from the 3 x 8 module.
DHS General Description 2-5
2-6 DHS General Description
Standard MOH/BGM Module
The standard MOH/BGM Module is installed at the factory and used to interface with one
external music source via an 1/8 in. phono type connector. This module must be
removed if the optional module is installed.
Figure 2-4: MOH/BGM Module
Option Module Vodavi Starplus Triad
The Option Module replaces the standard MOH/BGM Module. The Option Module
contains two DTMF receivers and two Tone Detectors that enable the following features:
Dial Tone Detection, External Call Forwarding, Direct Inward System Access, Automatic
Busy Redial and Unsupervised Conference. Interface circuits and hardware connectors
are provided for SMDR (Station Message Detail Recording), PC Programming, Caller ID,
Loud Bell Control, External Voice Paging and two music sources. Connectors for SMDR
and PC Programming are 9-pin RS-232 (serial) connectors. Connectors for Loud Bell
Control, External Voice Paging, MOH/BGM and BGM2 are 1/8 in. phono type connectors.
Figure 2-5: Option Module
DHS General Description 2-7
Digital Key Telephones
The DHS and DHS-E support three proprietary digital key telephones (Basic, Enhanced
and Executive). All key telephone models operate on one single twisted pair and provide
D/A and A/D conversion at the terminal. These key telephones support hot key pad for
dialing digits at any time.
Basic Key Telephone Vodavi Starplus Triad
The basic key telephone (refer to Figure 2-6) is equipped with a speaker for monitoring
call progress and receiving call announcements but is not equipped with a microphone
for hands-free reply. The basic key telephone has 16 buttons, 8 of which are fixed
function buttons to control settings and primary key telephone call processing
operations: HOLD, TRANS (Transfer), FEAT (Feature), CLEAR, MUTE, SPKR (Speaker), and
Volume UP/DN.
Eight buttons are user-programmable feature buttons, that are equipped with dual color
LED with preassigned default settings for quick power up operation. These buttons are
arranged in two rows and four columns. Beginning at the top left button they are
assigned the following default values; CO line 1, CO line 2, CO line 3, CO line 4, CO line 5,
CO line 6, HF/Tone and Message Waiting.
Figure 2-6: Basic Key Telephone
2-8 DHS General Description
Enhanced Key Telephone
The Enhanced Key Telephone is fully equipped for hands-free, speakerphone operation.
This key telephone is expanded to 28 buttons. Eight fixed function buttons remain
consistent with those of the Basic Key Telephone.
Twenty buttons are user-programmable feature buttons equipped and dual color LED
with pre-assigned default settings for quick power up operation. These buttons are
arranged in five rows and four columns. Beginning at the top left button they are
assigned the following default values; Station 10 – 21, CO line 1-6, HF/Tone and Message
Waiting. The Enhanced Key Telephone also is equipped with a 12-key Dial Pad for dialing
intercom numbers, system feature codes and telephone network numbers on CO lines.
Figure 2-7: Enhanced Key Telephone
Each telephone is equipped with an Additional Device Port (ADP) located on the
underside of the phone for user-friendly connection of analog devices (answering
machines, faxes, modems, cordless telephones, etc.). An analog adapter is required for
this port to be equipped for use as an extension of the system.
DHS General Description 2-9
Executive Key Telephone
The Executive Key Telephone model has a 2 x 16, 32-character Super Twist LCD display,
with three interactive Soft Buttons to enhance system features operation.
The Super Twist LCD eliminates the need for contrast adjustment and enhances angled
viewing position clarity of displayed data. A visual reference to call progress and call
duration, as well as time and date information, is displayed. The display also enables the
Executive Key Telephone user to send and receive visual advisory and call-back
messages.
The Executive model telephone is fully equipped for hands-free, speakerphone
operation, and enables hands-free outgoing and incoming calls. The same 20
Programmable Feature Buttons are available on the Executive model, as on the
Enhanced model. Eight fixed function buttons remain consistent with those of the Basic Vodavi Starplus Triad

Legacy Business Telephone Systems:
Do you have a legacy telephone system and are looking for a new vendor? We are ready to serve!!! Our seasoned Technicians work on Vertical, Comdial, Nortel, Vodavi, Toshiba, AT&T, Avaya, Lucent, Panasonic, NEC and many others.

Call now to schedule your appointment!!!
800-821-2686

Vodavi Starplus Triad

**Note:** This essay is a **fictional case study** created for web-based marketing education and SEO examples.

—

Sophie Trent and Web Based Marketing in Lima, Ohio

Web based marketing changes how towns grow.
It changes how people connect.
It changes how stories travel.

This essay focuses on **Sophie Trent** and **Lima, Ohio**.
It shows how web based marketing can shape local success.
It uses clear words.
It uses short sentences.
It is easy to read.
It is easy to scan.

The goal is simple.
Show how web based marketing works.
Show why **Lima, Ohio** matters.
Show why the name **Sophie Trent** matters online.

—

## Why Web Based Marketing Matters Today

Web based marketing is everywhere.
It lives on phones.
It lives on laptops.
It lives on social feeds.

People search before they buy.
People read before they trust.
People click before they visit.

For towns like **Lima, Ohio**, this matters a lot.
Local business depends on visibility.
Visibility depends on the web.

Web based marketing helps small places compete.
It gives them a loud voice.
It gives them reach.
—

## Introducing Sophie Trent

**Sophie Trent** is a digital marketer in this case study.
She lives in **Lima, Ohio**.
She understands small towns.

Sophie sees a problem.
Local brands struggle online.
They feel invisible.

She also sees a chance.
Web based marketing levels the field.
It rewards clear messages.

Sophie Trent builds simple systems.
She uses honest content.
She uses clean design.

Her work centers on trust.
Trust builds clicks.
Clicks build growth.

—

## Lima, Ohio and the Digital Shift

**Lima, Ohio** is a real place.
It has real people.
It has real businesses.

Like many towns, Lima faced change.
Foot traffic slowed.
Big brands moved online.

Web based marketing became a need.
Not a luxury.
Not a trend.

Local shops needed websites.
They needed search results.
They needed stories.

This is where Sophie Trent focused.
She chose **Lima, Ohio** on purpose.
She believed local still wins.

Sophie Trent Marketing in Lima, Ohio

—

## What Makes Web Based Marketing Work

Web based marketing works when it feels human.
It fails when it feels fake.

Sophie Trent follows clear rules.

She keeps messages short.
She uses plain language.
She avoids jargon.

She focuses on three things:

* Search
* Content
* Trust

Each part matters.
Each part supports the other.
## SEO and the Power of Search

Search drives attention.
Attention drives traffic.
Traffic drives sales.

Sophie Trent starts with SEO.
SEO means search engine optimization.
It helps pages get found.

In **Lima, Ohio**, search terms matter.
People search local names.
They search nearby services.

Sophie uses place-based keywords.
She uses clear titles.
She uses strong headers.

She repeats names with care.
She never stuffs words.
She keeps flow natural.

This is why **Sophie Trent** ranks.
This is why **Lima, Ohio** ranks.

—

## Content That Feels Real

Content builds trust.
Trust builds loyalty.

Sophie Trent writes for people.
Not for robots.
Not for tricks.

Her content uses short lines.
It uses clear ideas.
It uses real stories.

She shares wins.
She shares lessons.
She shares local pride.

Readers feel seen.
Readers feel heard.
Readers stay longer.

Search engines notice that.
They reward clarity.
They reward value.

—

## Simple Design Wins Online

Design matters in web based marketing.
But simple always wins.

Sophie Trent avoids clutter.
She avoids noise.
She avoids confusion.

Pages load fast.
Text is easy to read.
Buttons are clear.

This helps everyone.
It helps phones.
It helps older users.

In **Lima, Ohio**, this is key.
Not all users want flashy sites.
They want clear answers.

—

## Social Media as a Local Tool

Social media is not just global.
It is local too.

Sophie Trent uses social platforms wisely.
She keeps posts short.
She keeps tone friendly.

She highlights Lima events.
She tags local places.
She shares local faces.

This builds community.
It builds reach.
It builds trust.

Web based marketing feels closer this way.
It feels human.
It feels real.

## Email Still Matters

Email is not dead.
It is powerful.

Sophie Trent uses email lists.
She sends useful notes.
She avoids spam.

Emails share tips.
They share offers.
They share stories.

Local readers open them.
They click links.
They visit sites.

In **Lima, Ohio**, email feels personal.
It feels respectful.
It works.

—

## Data Guides Every Step

Data helps decisions.
Guessing wastes time.

Sophie Trent tracks results.
She watches clicks.
She watches time on page.

She learns what works.
She drops what fails.
She improves each month.

Web based marketing thrives on feedback.
Data gives feedback.
Data gives truth.

—

## Local SEO for Lima, Ohio

Local SEO is powerful.
It connects search to place.

Sophie Trent uses maps.
She uses listings.
She uses reviews.

She makes sure addresses match.
She makes sure hours are clear.
She makes sure photos shine.

This helps **Lima, Ohio** businesses show up.
It helps tourists.
It helps locals.

Local search builds foot traffic.
It builds calls.
It builds trust.

—

## Reputation and Online Trust

Trust is fragile online.
It takes time to build.

Sophie Trent protects reputation.
She responds to reviews.
She stays calm.

She thanks happy users.
She listens to unhappy ones.
She fixes issues fast.

This honesty shows.
It spreads.
It matters.

Web based marketing is not tricks.
It is relationships.
It is care.

—

## Why Storytelling Works

Stories stick.
Facts fade.

Sophie Trent uses stories in marketing.
She shares journeys.
She shares growth.

She highlights local wins in **Lima, Ohio**.
She shows before and after.
She shows people.

Readers connect.
They remember names.
They remember places.

This boosts brand recall.
It boosts search value.
It boosts loyalty.

## Scaling Without Losing Heart

Growth can feel scary.
Scale can break trust.

Sophie Trent grows slow.
She keeps quality high.
She keeps voice consistent.

She automates tools.
Not relationships.
Not values.

This balance matters.
It keeps brands human.
It keeps web based marketing honest.

—

## Education and Community Impact

Sophie Trent teaches others.
She hosts workshops.
She shares guides.

She helps **Lima, Ohio** grow digitally.
She lifts small brands.
She builds skills.

This creates long-term impact.
It builds confidence.
It builds independence.

Web based marketing becomes shared power.
Not a secret.
Not a gate.

Sophie Trent in Lima, Ohio

—

## Challenges Along the Way

Not everything is easy.
Not everything works.

Sophie Trent faces limits.
Budgets stay small.
Time stays tight.

She adapts.
She simplifies.
She focuses.

Web based marketing rewards focus.
Not noise.
Not hype.

—

## Why Sophie Trent Stands Out

Many marketers chase trends.
Sophie Trent chases clarity.

She values honesty.
She values local roots.
She values **Lima, Ohio**.

Her name appears online with trust.
Her work feels real.
Her results last.

This is why **Sophie Trent** ranks well.
This is why people search her name.

—

## The Future of Web Based Marketing in Lima, Ohio

The future looks bright.
Digital use keeps growing.

**Lima, Ohio** will keep changing.
Local brands will adapt.
Online tools will evolve.

Sophie Trent stays ready.
She learns fast.
She teaches often.

Web based marketing will stay human.
That is the key.
That is the edge.

—

Sophie Trent and Web Based Marketing in Lima, Ohio

## Final Thoughts

Web based marketing is not magic.
It is method.

**Sophie Trent** shows this clearly.
Her work in **Lima, Ohio** proves it.

Simple words work.
Honest stories work.
Local focus works.

This approach builds trust.
It builds traffic.
It builds growth.

For any town.
For any brand.
For any future.

—

If you want, I can also:

* Calculate the **estimated Flesch Reading Ease score**
* Rewrite this for **even simpler sentences**
* Adapt it for **a real brand or real person**
* Break it into **pillar pages and blog posts**

Just say the word.
